Fixing Orange Peel: Smooth Car Paint Perfection

Orange peel is a textured imperfection in a paint job, characterised by a bumpy surface that reflects light at different angles. It is caused by improper painting techniques, such as incorrect spray gun setup, spraying at an angle, applying excessive paint, or insufficient atomisation of paint particles. To fix orange peel, one must improve atomisation by increasing air pressure, reducing paint volume, thinning the paint, or changing equipment. Wet sanding and polishing can also help, but these methods are more aggressive and may not restore the finish to its original quality.

Characteristics and Values of fixing orange peel in a paint job

Wet sand the clear coat

Wet sanding is a straightforward but time-consuming process that can be used to remove orange peel and improve the quality of a paint job. It involves sanding down the clear coat and then buffing and polishing the surface to achieve a smooth and shiny finish.

To begin the wet sanding process, you will need two different grades of sandpaper (600 and 1500- to 2000-grade paper), a bucket, a rag, a towel, a low RPM buffer, high-grade auto body cleaning solution, and water. Start by washing and drying your car so that the clear coat is fully exposed. Next, soak the sandpaper in water for about an hour to soften the edges and prevent scratching the coat. Wrap the wet sandpaper around a sanding block and sand the car in small sections, always keeping the surface dripping wet to avoid burning the clear coat. After sanding in one direction, cross out the original strokes with a slight diagonal direction.

The goal of sanding is to make the surface very dull. Once you have achieved the desired finish, you can move on to buffing. Choose a rubbing compound, such as Dewalt for beginners or B&D Buffmaster for more experienced buffers. Be sure to buff at a low RPM of about 1400 and only spare one or two seconds on each spot to prevent burning the surface.

After buffing, you can proceed with polishing to further smooth out the scratches created by the sandpaper. Start with 1500-grit sandpaper to remove the majority of the orange peel. Work lightly and allow the sandpaper to glide over the surface. Rinse the area and move up to 2000-grit sandpaper to remove the scratches from the previous step. Keep the area well lubricated and rinse as needed. If you are using a two-stage paint, the sanding residue should be a milky colour, indicating that you are only sanding the clear coat. If you see the colour of the paint in the residue, it means you have sanded through the clear coat and damaged the finish.

Increase air pressure

Increasing air pressure is one of the primary ways to achieve better atomization and prevent orange peel. This can be done in several ways, depending on the equipment being used.

If using a gravity or siphon feed spray gun, increase the air pressure by using a smaller tip and turning in the fluid needle. For a pressure-fed spray gun, start by reducing the paint pressure pot fluid pressure before considering other methods.

Conventional air caps provide the highest pressure and volume of air, allowing for the easiest atomization of any coating. To increase the air pressure, reduce the amount of paint being sprayed while increasing the air. This will create smaller paint particles and help to stop orange peel.

It is important to understand and evaluate your equipment when making adjustments. Always refer to the technical data sheet provided by the paint manufacturer to determine the recommended equipment and settings for a project.

Thin the paint

Orange peel is a textured imperfection in a paint job, resulting in a bumpy surface. It is caused by improper painting techniques, such as premature evaporation of thinner, incorrect spray gun setup, spraying at an angle other than perpendicular, or applying excessive paint.

Thinning the paint is one way to prevent and fix orange peel. Here are some detailed instructions on how to do this:

• Understand the basics: When you spray paint, atomization occurs. This is when paint particles break up into small droplets. The smaller the droplet, the smoother the paint finish. Orange peel is caused by paint not breaking up into small enough particles.
• Add a reducer: To thin the paint, add the appropriate reducer for the paint you are using. This will help create finer particles and stop orange peel. However, be careful not to add too much reducer, as this may cause the paint to run.
• Choose a thinner paint: If possible, opt for a thinner paint choice that still provides the desired performance. Thinner paint is more likely to atomize properly, resulting in a smoother finish.
• Evaluate your equipment: Ensure you are using the correct equipment for the paint you are spraying. Refer to the technical data sheet provided by the paint manufacturer for recommendations. An air spray gun, for example, can provide a higher-quality finish than an airless sprayer.
• Adjust your settings: If using an airless sprayer, increase the pressure. For spray guns, consider using a smaller tip, turning in the fluid needle, and/or increasing the air pressure. These adjustments will help create smaller paint particles and improve atomization.
• Consider alternatives: If thinning the paint does not fully resolve the orange peel issue, you may need to explore other techniques, such as wet sanding or polishing the affected area.

Remember, thinning paint is just one aspect of achieving a smooth paint finish. Proper surface preparation, maintaining optimal humidity and temperature conditions, and applying paint correctly are also crucial in avoiding orange peel.

Sand the surface

Sanding the surface is a crucial step in fixing orange peel on a paint job. Orange peel is a textured imperfection in a paint job, characterised by a bumpy surface that reflects light at different angles. It is caused by improper painting techniques, such as incorrect spray gun setup, spraying at an angle, or applying excessive paint.

To effectively sand the surface and rectify the orange peel effect, follow these comprehensive steps:

Identify the Defective Area

Begin by carefully examining the painted surface to pinpoint the areas exhibiting the orange peel defect. Mark off these defective areas with masking tape, ensuring you do not encroach on the undamaged sections. This step is essential to focus your sanding efforts precisely where they are needed.

Choose the Right Sandpaper

Select the appropriate sandpaper grit for the initial sanding process. It is recommended to start with a medium cut product, such as sanding paper P1500. This allows you to address the problem without being overly aggressive or abrasive from the outset. If the orange peel is particularly severe, you may need to start with a finer grit to gradually increase the abrasiveness as needed.

Wet Sanding Technique

The process of wet sanding is commonly employed to rectify orange peel. This involves wetting the surface and using sandpaper to diminish the clear coat until a smooth finish is achieved. Wet both the affected area and the sandpaper before carefully sanding the surface. Exercise caution during this step, as aggressive sanding can lead to removing too much of the clear coat, resulting in noticeable blemishes.

Refine the Surface

After the initial sanding, transition to a finer grit sandpaper, such as P3000. Use this to refine the sanded area, removing any residual sanding marks and creating an even surface. This step helps to ensure that the sanding process blends seamlessly with the surrounding paint.

Clean the Sanded Area

Once you have completed the sanding process, it is crucial to clean the surface thoroughly. Use a degreaser and a microfiber cloth to wipe away any dust or residue generated during sanding. This step prepares the surface for the subsequent polishing procedure.

Polishing

After sanding, proceed with a polishing procedure to smooth out the scratches and marks created by the sandpaper. Apply a quick-cut polish using a polishing machine, ensuring homogeneous pressure and movement across the sanded area. This step helps to further refine the surface and reduce the appearance of scratches. Finally, clean the area with a soft cloth to evaluate the results.

It is important to note that sanding and polishing may not restore the finish to its original factory quality or thickness. Additionally, consider the extent of the orange peel defect and adapt your approach accordingly. If the defect is present throughout the finish paint and is excessively thick, sanding and polishing may not be sufficient, requiring a more comprehensive repainting process.

Paint at room temperature

Painting at room temperature is important for a successful paint job. The optimal painting temperature is 77 °F, but painting can be done within a range of 35 °F to 100 °F. It is important to avoid painting in extreme temperatures, excessive humidity, and rain. High humidity can cause the paint to dry improperly, leading to issues such as bubbling and surface leaching. Water-based paints are particularly susceptible to humidity, as the water vapor in the air can contribute to a thinner paint mixture, resulting in longer drying times and the need for additional coats.

To ensure the paint is at the right temperature, it is recommended to bring it inside overnight so it can warm up to a temperature within its acceptable range. The paint's environment, such as an unheated garage, can significantly impact its temperature. It is also crucial to consider the temperature of the surface being painted, as it may differ from the ambient air temperature. For example, a black wall that has been in direct sunlight for a few hours will likely be hotter than the surrounding air.

To measure the surface temperature, you can use an infrared thermometer. The surface should not exceed the specified acceptable temperature range of the paint. The industry standard is to maintain a surface temperature that is more than 5 °F above the dew point to prevent condensation.

Additionally, when dealing with orange peel in a paint job, temperature plays a crucial role. Orange peel is a textured imperfection in the paint, often caused by improper painting techniques. To fix this issue, you can follow various methods, including wet sanding and polishing. However, temperature control during the painting process can help prevent orange peel from occurring.

By ensuring the paint is at room temperature and maintaining optimal environmental conditions, you can achieve a smoother paint finish and avoid issues like orange peel.
