Easy Xbox One Paint Repair Guide

If the paint on your Xbox One has been rubbed off, you can fix it by repainting the console. This will require disassembling the Xbox, cleaning the shell with dishwashing liquid and water, and then painting it with vinyl paint from an auto shop. You can also sand the console before painting to get a better finish. It is important to note that painting your Xbox may cause heat issues and will void any warranty you have on the console.

Characteristics and Values Table

Disassemble the Xbox One

To disassemble the Xbox One, you will need to first take off the left side panel by pulling it off, starting at the front edge. Next, remove the side piece by sliding it back; it should just fall off.

After that, you will need to remove the rubber feet from the bottom of the console. This can be done by pulling them off, but be careful as adhesive will remain on the plastic. You will need replacement double-sided tape or glue for reassembly.

Now, you will need to remove the screws securing the upper metal shield to the chassis. There are eight 64 mm T9 Torx screws. Once these are removed, the entire Xbox One assembly simply lifts off from the lower case.

With the console open, you can now access the internal components, such as the hard drive and optical drive, for repair or replacement. Keep in mind that opening the console will void any warranty you may have.

Sand the console

To fix rubbed-off paint on your Xbox One, you will need to sand, prime, and repaint the console. This process will void your warranty, so proceed with caution.

Before you begin, ensure you can live without your Xbox for a few days. Disassembling the console is a straightforward process, but it is important to be careful and deliberate in your actions. First, remove the left side panel by pulling it off, starting at the front edge. Next, remove the side piece by sliding it back; it should come off easily.

Now it is time to sand your Xbox. Take dry 220-grit sandpaper and rough up all external surfaces. Be careful around the vents, as they can be tricky to sand. You may also want to sand off any remaining paint on the buttons, but be sure to avoid sanding any internal components that are crucial to the function of the console.

Once you have finished sanding, you can move on to priming and painting the console. Be sure to choose a paint specifically designed for vinyl surfaces, which can be found at auto supply stores. Apply light coats of paint, building up the colour gradually. Allow each coat to dry before applying the next, and be prepared to apply as many layers as needed for your desired look and coverage.

Clean the shell

To clean the shell of your Xbox One, you will first need to disassemble the console. This involves removing the left side panel and then the side piece by sliding it back. You will then need to sand the external surfaces of the console with 220-grit sandpaper to rough them up. Be careful when sanding the vents as they can be tricky.

Once you have sanded the shell, mix some dishwashing liquid with water and use this solution to thoroughly clean the surface of the shell. Rinse the shell with clean water and let it dry completely before proceeding to the next steps.

It is important to note that disassembling your Xbox One will void any warranty you may have. Additionally, be cautious when handling the internal components of the console to avoid causing any damage.

After cleaning and drying the shell, you can begin the process of painting. It is recommended to use tape to cover areas that you do not want to paint or that require different colours. Auto supply stores offer paint for vinyl, which is suitable for this purpose.

Apply light passes of paint, building up the colour gradually. Multiple coats may be necessary to achieve the desired coverage and finish. Allow sufficient drying time between coats, and follow the manufacturer's instructions for the paint you are using.

Tape off areas for different colours

To fix rubbed-off paint on an Xbox One, you will need to disassemble the console, clean the shell, and then repaint it. Taping off areas for different colours is an important step in the painting process. Here is a step-by-step guide:

• Disassemble the Xbox One: Start by removing the left side panel, then the side piece by sliding it back. You may need to unscrew some parts, so have a screwdriver handy.
• Clean the Shell: Once the console is disassembled, use dishwashing liquid and water to clean the shell of the Xbox. This will remove any dirt, dust, or grease that could interfere with the new paint job. Allow the shell to dry completely before moving on to the next step.
• Tape Off Areas: Use painter's tape to mask off the areas you do not want to paint or that will be painted a different colour. Be sure to press down the edges of the tape firmly to prevent paint bleed.
• Choose Your Paint: It is recommended to use paint for vinyl, which can be found at auto supply stores. Choose a paint colour that suits your preference.
• Prepare the Work Area: Set up your work area in a well-ventilated space, preferably outdoors. Place the Xbox components on a flat surface, such as a table, and lay down a drop cloth or newspaper to protect the surface from paint.
• Prime the Surface: Depending on the type of paint you choose, you may need to apply a primer to the surface before painting. This will help the paint adhere better and create a more even finish.
• Paint Light Coats: Following the basic steps of spray painting, hold the can 8-16 inches away from the surface and spray in side-to-side motions. Start before and end after the edge of the area you are painting. Apply several light coats rather than one heavy coat to build up the colour gradually. Allow each coat to dry before applying the next.
• Remove the Tape: Once the paint is dry to the touch, carefully remove the painter's tape to reveal the masked-off areas.
• Reassemble the Xbox: After allowing the paint to cure for 24 hours, you can reassemble the Xbox One by following the disassembly steps in reverse. Be gentle when handling the freshly painted components.

Remember to work in a well-ventilated area when painting and always follow the directions on the paint can. With these steps, you can successfully tape off areas for different colours and achieve a professional-looking paint job on your Xbox One.

Reassemble the console

To reassemble your Xbox One after painting, you will need to follow the disassembly process in reverse. However, there are a few things to keep in mind to ensure a smooth reassembly.

Firstly, it is recommended to let the paint dry for about 24 hours before reassembling the console. This will ensure that the paint is completely dry and reduce the risk of smudging or damaging your new paint job.

When reassembling, it is suggested to leave the front plate until last. This makes it easier to put on the top piece and connect the wires. To connect the wire attaching the front panel to the circuit board, ensure that any paint on the contacts of the wire is removed. Then, insert the wire under the brown piece and push it in. The loop piece on the back of the connector should fit over the connector. If it doesn't, you will need to remove the wire and try again, pushing the wire further in.

Additionally, if you removed the rubber feet from the bottom of the console during disassembly, you will need to replace the adhesive. You can use double-sided tape or glue to secure the rubber feet back in place.

Finally, be cautious when handling the internal components of your Xbox One. It is important to ensure that all connections are secure and no paint interferes with the proper functioning of the console. Once you have followed these steps and carefully reassembled your Xbox One, you can power it on and enjoy your newly painted console.
