Troubleshooting Guide: Airbrush Not Spraying Paint

If your airbrush is not spraying paint, there are several things you can do to troubleshoot the problem. First, check that the paint is not too thick by emptying your paint reservoir, cleaning it thoroughly, and then filling the reservoir with plain water or an airbrush thinner to see if the airbrush sprays. If it does, your paint is too thick and you will need to thin it out. Next, check that the needle is moving when you pull back the trigger. If it is not, try tightening the needle chuck or check if the needle is stuck from dried paint. If the needle is bent, you will need to get a new one. If the problem is not with the paint or the needle, you may have a clog in the nozzle or paint tube. To check this, put some airbrush cleaner in the cup and see if it comes out of the nozzle. If it does not, you may have a clog that needs to be removed or a damaged component that needs to be replaced.

Characteristics and Values Table:

Check if the paint is too thick

If your airbrush is blowing air but no paint is coming out, the paint may be too thick to be sprayed properly. To test this, empty your paint reservoir, clean it thoroughly, and fill the reservoir with plain water, an airbrush thinner, or an airbrush cleaner. If the airbrush sprays the liquid, your paint is too thick.

In this case, thin down your paint until it is thin enough to be sprayed. You should also clean the airbrush's needle and reservoir to ensure that any remaining thick paint does not hinder the flow of the thinned paint. Your paint may also have lumps, in which case you should either use a different paint or properly mix in thinner to ensure no lumps enter the airbrush.

You can also increase the air pressure slightly to help with dispersing the thicker paint. However, be aware that having the pressure too high can also cause problems.

If thinning the paint does not work, the issue may be caused by something else. For example, you may have forgotten to tighten the needle chuck, or the needle may be stuck from dried paint.

Ensure the airbrush needle is not stuck

If your airbrush is not spraying paint, it could be because the needle is stuck. To fix this, first, do not force the needle. Forcing it may damage the needle bearing. Instead, try loosening the needle lock nut. If the trigger now works, the problem was not with the needle. If the needle is still stuck, try pushing it forward lightly. If the needle comes free, push it forward enough to wipe it clean with a thinner.

If the needle is still stuck, you may need to leave the front part of the airbrush soaking for a longer period of time, or use a stronger cleaner or solvent. Be careful of the air valve assembly, as some solvents can damage it. Once the needle is free and clean, pull it out, give the brush a good cleaning, and you should be good to go.

To prevent the needle from getting stuck, clean it with alcohol or airbrush cleaner. You can also run a couple of paint cups of lacquer thinner through the airbrush if you plan on using it again within 24 hours. If you are going to let it sit for an extended period, disassemble it and clean the individual parts with a paper towel or Q-tip and lacquer thinner.

Clean the airbrush thoroughly

If your airbrush is not spraying paint, it is important to clean it thoroughly to remove any dried paint, which is harder to remove. First, empty the paint reservoir and clean it thoroughly. Then, fill the reservoir with plain water, an airbrush thinner, or an airbrush cleaner. If the airbrush sprays the liquid, your original paint was too thick.

If the needle is stuck, remove it and wipe it with a thinner. You can also use an old toothbrush to clean the nozzle. It is important to clean the needle and reservoir thoroughly to ensure that no thick paint is hindering the flow of the thinner paint.

If the airbrush is still not spraying paint, disassemble the airbrush and check if the needle is stuck from dried paint or if it is bent. If the needle is dirty, clean it with alcohol or an airbrush cleaner. If the needle is bent, you will need to get a new one.

Compressed air from an air compressor can be used to dry out the airbrush and prevent water marks. Special grease can also be used on the needle and trigger.

Check for blockages in the nozzle

If your airbrush is not spraying paint, it could be due to a blocked nozzle. This is often caused by dried paint or gunk left behind from previous use. To check for blockages in the nozzle, start by disassembling the airbrush. Remove the needle and check if there is any dried paint or gunk buildup on it. Clean the needle with a cloth dampened with airbrush cleaner or alcohol. You can also try rotating the needle in the nozzle with slight pressure to remove any blockages.

If the needle appears clean and blockage-free, focus on the nozzle itself. Soak the nozzle in airbrush cleaner or a mixture of IPA/water for some time to loosen any dried paint or gunk. Use a thin tool, such as a brass rod or a sewing needle, to gently poke inside the nozzle and remove any dissolved or loosened paint. If the nozzle is too small for tools to reach inside, consider purchasing airbrush cleaning tools with long, thin scrapers or brushes specifically designed for this purpose.

If your airbrush has a floating nozzle, there is no gasket between the nozzle and the main body of the brush. In this case, rub a little beeswax on the nozzle and check if there are any bubbles. If the bubbles disappear, you may need to replace the nozzle. For airbrushes with screw-in nozzles, ensure you haven't lost the gasket, as over time, gaskets can be compressed and leak.

If your airbrush continues to have issues after attempting these fixes, there may be another cause for the problem. Check other components, such as the air pressure, paint consistency, and needle movement, to ensure they are functioning correctly.

Adjust the air pressure

If your airbrush is not spraying paint, there could be an issue with the air pressure. Here are some steps to help you adjust the air pressure and fix the problem:

Firstly, check if the air pressure is set too low. If the pressure is insufficient, increase it until the paint atomizes. It is recommended to set the air pressure to no lower than 20 psi, as this should be enough pressure for properly thinned paints and water to spray well.

If you are using a siphon feed airbrush, keep in mind that they generally require higher air pressure to operate properly. In such cases, the issue might be that the pressure is not high enough for the specific type of airbrush.

If you are experiencing a rough sandpaper finish, orange peel, runs, or speckles on the painted surface, the air pressure might be a contributing factor. A rough sandpaper finish could be due to the airbrush being held too far away, causing the paint droplets to dry before they hit the surface. To fix this, try holding the airbrush closer to the object. Orange peel occurs when paint droplets don't flow together smoothly, which can be addressed by slowing down and applying the paint a little heavier. Runs happen when the paint is applied too heavily or is too thin, so adjust the application technique accordingly. Speckles, or stippling, can occur when the air pressure is too low for the paint's viscosity. To eliminate speckles, increase the air pressure or adjust the distance from the nozzle to the surface.

If your airbrush is expelling air but very little or no paint, the issue could be related to the paint consistency or air pressure. Try thinning the paint further, as paint that is too thick may not flow easily, especially at lower pressures. Additionally, ensure that you are using the correct thinners for your paint to prevent clogging issues.

By following these steps and adjusting the air pressure accordingly, you should be able to resolve issues related to insufficient or improper air pressure in your airbrush.
